High efficiency moulder with slice cutting VH-M621HS, four cutter shafts and two saw shafts
Slice Cutting 4-Side Moulder VH-M621HS
| Four Side Moulder with cutter saw VH-M621HS combines four side moulder with 4 spindles and Multiple Rip Saw in one, to achieve multiple functions. It can largely reduce processing time of wood and improve efficiency. Professional solutions: high-volume sauna board production, wall hanging wood board, antiseptic timber, shuttered window and other solid wood material processing. It is a special type of machine for wood planning and sawing. By using this machine number of worker can be reduced. |
| The machine has four side planing and slice double functions which can save time and enhance capacity effectively.
Inverter feed speed of 6-30m/min.
All spindle adjustments are carried out in front of the machine for convenience
Individual motor to each spindle to ensure maximm cutting.
Hard chormb treament has been adopted for the durability of work table surface.
|
| Model | | VH-M621HS |
| Specification | Working width | 25-210 |
| | Working thickness | 8-140 |
| | Working table length | 1970 |
| | Feeding speed | 6-36 |
| | Main spindle diameter (mm) | Φ 40 |
| | Main spindle revolution(r/min) | 6500 |
| | Air pressure (Mpa) | 0.6 |
| Motor power(KW) | 1st LowerShaft | 5.5kw/7.5HP |
| | Right vertical spindle | 5.5kw/7.5HP |
| | Left vertical spindle | 7.5kw/10HP |
| | 1st UpperShaft | 7.5kw/10HP |
| | Right Saw Shaft | 18.5kw/25HP |
| | Left Saw Shaft | 18.5kw/25HP |
| | Feeding beam lifting | 0.55kw/0.75HP |
| | Feeding motor | 5.5kw/7.5HP |
| | Left discharging motor | 0.75kw/1HP |
| | Right discharging motor | 0.75kw/1HP |
| | Total power | 70.5kw/94HP |
| Cutter diameter | 1st Lower Shaft | Φ 125 |
| | Right Vertical spindle | Φ 125-Φ 180 |
| | Left vertical spindle | Φ 125-Φ 180 |
| | 1st Upper Shaft | Φ 125-Φ 180 |
| | Right saw arbor | Φ 180-Φ 300 |
| | Left saw arbor | Φ 180-Φ 300 |
| | Saw shaft speed | 4500 |
| | Saw shaft diameter | Φ50 |
| Remark | Feeding wheel diameter (mm) | Φ140 |
| | Dust outlet diameter (mm) | Φ140 |
| | Overall dimensions (mm) | L4800*W1900*H1940 |
| | Suttle (kg) | 4300 |
