Situated in Lunjiao town, Shunde district of Foshan city, the biggest woodworking machinery
production base as well as “the Chinese leading woodworking machinery town”, V-HOLD
woodworking machinery manufacture Co.,Ltd is a large well-known company integrated
woodworking machinery research, processing, marketing as well as application service.
Chain plates and guiderails ,with high hardness and good wear resistance,are made from special materials and
technology.Microcomputer-controlled automatic lubrication pump improves machine's service life by supplying fuel
timely and quantitatively at fixed place for key parts of chain plates and guiderails.Multiple lamina from hurting people
for flying out of rebound. Special-designed bilaterally guiding rule makes it easy for users to use
interchangeably,thus to protect the machine precision from long-term unilateral usage of chain plates.
Available to be fitted with laser unit and can preview. precision of the saw path for long length of the woodworking
pieces with less loss of material.
High precision Single Rip Saw Trimming Saw Bottom Saw with working thickness 80mm
V-HOLD Single Rip Saw VH-MJ163C
 |  |
| Special design and material for chain and rail system can ensure stable feeding and high cutting accuracy and will also extend its service life. | One more level of protection of the anti-kickback finger guard on the table provides more safety. |
Situated in Lunjiao town, Shunde district of Foshan city, the biggest woodworking machinery production base as
well as “the Chinese leading woodworking machinery town”, V-HOLD woodworking machinery manufacture
Co.,Ltd is a large well-known company integrated woodworking machinery research, processing, marketing as
well as application service.
Founded in 1996, V-HOLD commits itself to provide the most secure, reliable, efficient, energy-saving,
economical production equipment for the customers around the world. Nowadays, most of the products
including 4-Side Moulder, Double Side Planner,Single Rip Saw, Multiple Rip Saw, Multiple Rip Saw
with Double Side Planner , and Automotive Floor Production Line have passed ISO9001: 2000 quality
system
| SPECIFICATION AND MODEL | MJ163C |
| Max. Saw blade diameter (mm) | >Φ 400 |
| Max. Working width (mm) | —— |
| Max. working thickness (mm) | 80 |
| Cutting width (mm) | 410 |
| Main spindle revolution (r/min) | 3300 |
| Spindle diameter (mm) | >Φ 50.8 |
| Feeding speed (m/min) | 7-19 |
| Feeding motor power (kw) | 1.5 |
| Main motor power (kg) | 7.5 |
| Lubricate pump motor power (w) | 20 |
| Total power (kw) | 9.02 |
| Working tabie sizer (mm) | >1720>x912 |
| Dimension (mm) | >1950x1920x1300 |
| Net weight (kg) | 1100
|
 | Hidden lubrication system located insied machine frame to protect its serivce life. |
Thanks for the trust and support of our customer. V-HOLD will consistently stick to the belief
that: Profession and concentration accomplish excellent brand
Product Tags:
|
|
High Precision Industrial Table Saw , 380V / Customized Electric Table Rip Saw Machine Images
|
