Suitable for board type furniture,butch ark door,etc;
Frequency control of motor speed, high presision conveyor chain rolling guide feed system;
Active on pressure strip, with electric lift;
Double linear guide, ball screw motor adjustable wide.
Because of profession,we become more professional.
 |  |
| Frequency control of motor speed,high precision conveyor chain rolling guide feed system. | Adopted widen gy high precision linear orbit,machine can run in precision and wearable.It assure the precision when widen the working size,also can guarantee to fit your highly requirement for setting the working width. |
| Specification and model | VH-MX2626D |
| Feeding speed | 6-30m/min |
| Min.working width | 100mm |
| Max.working width | 800mm |
| Min.working length | 300mm |
| Max.working length | 2600mm |
| Min.working thickness | 10mm |
| Max.working thickness | 60mm |
| Feed motor power | 3kw |
| Scoring saw motor power | 3kw x2 |
| Main saw motor power | 4kw x2 |
| Vertical spindle motor power | 5.5kw x2 |
| Maximum cutter diameter | Φ200mm |
| Max. Saw blade diameter | Φ230mm |
| Extraction outlet size | Φ120mm |
| Sawing shaft diameter | Φ25.4mm |
| Width adjusting motor power | 0.75kw |
| Total power | 29.25kw |
| Spindle speed | 6000 |
| Power take-off and landing | 0.25kw |
| Air pressure | 0.6Mpa |
| The length from feeding end of top pressing beam to dog | 800mm |
| Sawing shaft rotation | 2800 |
| Bottom saw blade size | 230mm |
| Top saw blade size | 230mm |
| Main spindle dimension | Φ40mm |
| Vertical spindle rotation | 6000 |
The main electrical componentsare import and famous
Adjusting width by high precision ball screw
The floor plates are sent into the running bearings of the machining track with material feeder and delivery rubber
rollers, and the guide rails are made with extra hard materials ensuring the machining precision.
1. The floor plates are sent into the running bearings of the machining track with the material feeder and delivery
rubber rollers,and the guide rails are made with extra hard materials ,ensuring the machining precision.
2. With the imported PLC and the frequency conversion device,the double-end miler works very smooth.
3. Forcefully feeding decelerator features speed regulation by frequency inverter.
4. With the built-in cleaning brush wheel,the dust inside the track guide rail can be cleaned automatically.
5. With the compact sawing shaft mechnism,the cutters are closed to the pressing belt, ensuring the machining stablility.
6. Structure acting as ball-screw makes machine have more accurate adjustment.
Situated in Lunjiao town, Shunde district of Foshan city, the biggest woodworking machinery
production base as well as “the Chinese leading woodworking machinery town”, V-HOLD
woodworking machinery manufacture Co.,Ltd is a large well-known company integrated
woodworking machinery research, processing, marketing as well as application service.
